Diesel Resistant Heat Shrinkable Cable Marker Sleeve

Model: HMS

HMS cable marker sleeve is diesel resistant heat shrink tubing used for the identification of wires and cables. This diesel resistant heat shrinkable cable marker sleeve is suitable for applications where wires or cables are exposed to organic fluids and diesel oils.

Standard

AMS-DTL-23053/6 Class 1, NF F 00608
Categories A&H, SAE-AS 81531, MIL-STD-202F/Method 215J, RoHS

Features
  • Material: fabricated from irradiated, thermally stabilized, flame retarded, modified polyolefin compound
  • Application: military, defense, aerospace, marine, etc.
  • Operating temperature range: -55℃～+135℃
  • Minimum recovery temperature: +120℃
  • Maximum storage temperature: +50℃
  • Shrink ratio: 2:1, 3:1
  • Color: white, yellow, other colors are available upon request
  • Printing: single sided printing or double sided printing
  • Supplied format: ladder-style or continuous sleeve
  • Recommended printer: thermal transfer printer or laser printer
  • Recommended ribbon: N85 resin ribbon, black, 100mm(width)×300m(length)
Dimensions

Shrink ratio-2X

Order Code As Supplied (mm) As Supplied (mm)
ID (D) Flatten Width (W2) Double Wall Thickness ID (d) Single Wall Thickness
AMS-M-2X-1.6 2.00±0.20 3.7±0.3 0.48±0.10 ≤0.79 0.45±0.06
AMS-M-2X-2.4 2.79±0.20 5.0±0.3 0.48±0.10 ≤1.18 0.49±0.06
AMS-M-2X-3.2 3.64±0.23 6.3±0.4 0.48±0.10 ≤1.59 0.51±0.06
AMS-M-2X-4.8 5.26±0.25 8.9±0.4 0.49±0.10 ≤2.36 0.54±0.06
AMS-M-2X-6.4 6.92±0.28 11.5±0.4 0.50±0.10 ≤3.18 0.56±0.06
AMS-M-2X-9.5 10.2±0.32 16.7±0.5 0.51±0.11 ≤4.75 0.59±0.06
AMS-M-2X-12.7 13.5±0.36 21.8±0.6 0.52±0.11 ≤6.35 0.60±0.07
AMS-M-2X-19- 20.1±0.40 32.2±0.6 0.53±0.11 ≤9.53 0.62±0.07
AMS-M-2X-25- 26.7±0.45 42.5±0.7 0.55±0.12 ≤12.7 0.63±0.07
AMS-M-2X-38- 39.8±0.51 63.2±0.8 0.57±0.12 ≤19.1 0.64±0.07
AMS-M-2X-51- 53.0±0.56 83.9±0.9 0.58±0.13 ≤25.4 0.64±0.08
AMS-M-2X-76- 79.4±0.56 125.3±1.0 0.59±0.13 ≤38.1 0.64±0.09

Shrink ratio-3X

Order Code As Supplied (mm) As Supplied (mm)
ID (D) Flatten Width (W2) Double Wall Thickness ID (d) Single Wall Thickness
AMS-M-3X-1.6- 2.00±0.20 3.7±0.3 0.47±0.10 ≤0.53 0.52±0.06
AMS-M-3X-2.4- 2.79±0.20 5.0±0.3 0.47±0.10 ≤0.79 0.57±0.06
AMS-M-3X-3.2- 3.64±0.23 6.3±0.4 0.48±0.10 ≤1.06 0.61±0.06
AMS-M-3X-4.8- 5.26±0.25 8.9±0.4 0.49±0.10 ≤1.59 0.67±0.06
AMS-M-3X-6.4- 6.92±0.28 11.5±0.4 0.50±0.10 ≤2.36 0.71±0.06
AMS-M-3X-9.5- 10.2±0.32 16.7±0.5 0.52±0.11 ≤3.18 0.77±0.06
AMS-M-3X-12.7 13.5±0.36 21.8±0.6 0.53±0.11 ≤4.75 0.80±0.07
AMS-M-3X-19- 20.1±0.40 32.2±0.6 0.55±0.11 ≤6.35 0.84±0.07
AMS-M-3X-25- 26.7±0.45 42.5±0.7 0.56±0.12 ≤8.47 0.86±0.07
AMS-M-3X-38- 39.8±0.51 63.2±0.8 0.57±0.12 ≤12.9 0.89±0.07
AMS-M-3X-51- 53.0±0.56 83.9±0.9 0.57±0.1 ≤17.2 0.90±0.08
AMS-M-3X-76- 79.4±0.56 125.3±1.0 0.57±0.13 ≤25.8 0.92±0.09
