Single Wall Heat Shrink Tubing

Model: RSFR-HCB(H)

Ultra thin wall, halogen free, flexible heat shrinkable tubing

RSFR-HCB(H) is halogen free heat shrink tubing that provides optimal protection of wiring and cables from abrasion and moisture in various application conditions. Ultra thin wall makes the heat shrink tubing works well in confined places.

Features
  • Shrink ratio: 2:1
  • Ultra thin wall
  • Flexible
  • Halogen free
  • Flame retardant
  • low smoke generation if burning
  • Continuous operating temperature: -55℃ to 125℃
  • Fully shrink temperature: 110℃
  • RoHS and Sony compliant
Typical Applications
  • Electrical insulation
  • Electronic component protection
  • Strain relief for connectors and splices
  • Protection against mechanical damage and abrasion
  • Moisture and corrosion resistance
  • Wire bundling
  • Wire harnessing
Technical Data
Property Test Method Typical Performance
Tensile strength (MPa) ASTM D 2671 ≥10.4
Ultimate elongation (%) ASTM D 2671 ≥200
Tensile strength after heat aging (MPa) 158℃×168h ≥7.3
Ultimate elongation after heat aging (%) 158℃×168h ≥100
Longitudinal change (%) ASTM D 2671 -5%～+5%
Flammability ASTM D 2671 C method VW-1
Dielectric strength (kV/mm) ASTM D 149 ≥15
Volume resistivity (Ω.cm) ASTM D 876 ≥1014
Dimensions
Size As Supplied After Recovery Standard Package
inch mm Internal Diameter (mm) Internal Diameter (mm) Wall Thickness (mm) Spool Length (m/spool)
1/16 1.0 1.4±0.2 ≤0.65 0.20±0.10 200
1.5 1.9±0.2 ≤0.85 0.20±0.10 200
3/32 2.0 2.4±0.2 ≤1.00 0.22±0.10 200
2.5 2.9±0.2 ≤1.30 0.25±0.10 200
1/8 3.0 3.4±0.2 ≤1.50 0.28±0.10 200
3.5 3.9±0.2 ≤1.80 0.28±0.10 200
4.0 4.4±0.2 ≤2.00 0.30±0.10 200
3/16 4.5 4.9±0.2 ≤2.30 0.30±0.10 100
5.0 5.5±0.2 ≤2.50 0.32±0.10 100
1/4 6.0 6.5±0.2 ≤3.00 0.32±0.10 100
5/16 7.0 7.5±0.3 ≤3.50 0.32±0.10 100
8.0 8.5±0.3 ≤4.00 0.32±0.10 100
3/8 9.0 9.5±0.3 ≤4.50 0.35±0.10 100
10.0 10.5±0.3 ≤5.00 0.35±0.10 100
11.0 11.5±0.3 ≤5.50 0.40±0.10 100
1/2 12.0 12.5±0.3 ≤6.00 0.40±0.10 100
13.0 13.5±0.3 ≤6.50 0.40±0.10 100
14.0 14.5±0.3 ≤7.00 0.40±0.10 100
5/8 15.0 15.5±0.4 ≤7.50 0.40±0.10 100
16.0 16.5±0.4 ≤8.00 0.40±0.10 100
17.0 17.5±0.4 ≤8.50 0.40±0.10 100
3/4 18.0 18.5±0.4 ≤9.00 0.42±0.10 100
20.0 20.5±0.5 ≤10.0 0.45±0.10 100
22.0 22.5±0.5 ≤11.0 0.45±0.10 100
1 25.0 25.5±0.5 ≤12.5 0.45±0.10 50
